Main parameter

1) Motion control 3-6 Axis(X,Y,Z,A,B,C) for option,max frequency output 460Khz/Axis;

2) Main power supply 24VDC,Current should higher than 1A;

3) IO Power is 24VDC power supply input,current should higher than 1A;

4) IO Power is 24VDC power supply input,current should higher than 1A. (By the IO power supply,system

already supply the power for IO ports.So no need the external power supply for IO port anymore.);

5) 18 opto-isolated digital input ports,16 opto-isolated digital output ports;

6) 1 analog output port of 0-10V adjustable speed for spindle (can change to PWM output port);

7) ARM motion control chip;

8) Compatible with Standard MPG and also Digital Dream MPG.
